ABP Scaffolding
ABP Scaffolding
Cup Lock Scaffold is a Modular Safety Erect Scaffolding System. It includes a complete range of components: Scaffold System of Cup Lock Scaffolding Standard, Cuplock Ledgers, Diagonal Braces, Intermediate Transoms, Hop Up Bracket, Steel Ladders, Scaffold Stairs, and Screw Jacks.
Hot-dip galvanized steel. Ø 48.3 x 3.2 mm. Equipped with Top Cups and Bottom Cups in which Ledgers and Braces are to be mounted. Distance between Bottom Cup: 500 mm.
| Art. | Length (m) | Weight (Kg) | Detail |
|---|---|---|---|
| OSC-S-050 | 0.50 | 3.53 | - |
| OSC-S-100 | 1.00 | 6.31 | - |
| OSC-S-150 | 1.50 | 9.05 | - |
| OSC-S-200 | 2.00 | 11.82 | - |
| OSC-S-250 | 2.50 | 14.57 | - |
| OSC-S-300 | 3.00 | 17.34 | - |
Hot-dip galvanized steel. Ø 48.3 x 3.0 mm. Mounted into the space between Top Cup and Bottom Cup with the Blade, securing a right-angled scaffold. Also serves as a guardrail.
| Art. | Length (m) | Weight (Kg) | Detail |
|---|---|---|---|
| OSC-L-060 | 0.6 | 2.47 | - |
| OSC-L-100 | 1 | 3.92 | - |
| OSC-L-120 | 1.2 | 4.28 | - |
| OSC-L-130 | 1.3 | 5.01 | - |
| OSC-L-150 | 1.5 | 5.73 | - |
| OSC-L-180 | 1.8 | 6.81 | - |
| OSC-L-200 | 2 | 7.54 | - |
| OSC-L-250 | 2.5 | 9.35 | - |
Hot-dip galvanized steel. Mounted into the space between Top Cup and Bottom Cup with the swivel Blade. Diagonal braces should be placed on at least every fifth section starting with the outer ones.
| Art. | Length (m) | Weight (Kg) | Detail |
|---|---|---|---|
| OSC-B-1 | 1.8*1.5 | 8.25 | - |
| OSC-B-2 | 1.8*2.0 | 9.31 | - |
| OSC-B-3 | 2.5*1.5 | 9.99 | - |
| OSC-B-4 | 2.5*2.0 | 10.86 | - |
| OSC-B-5 | 3.0*2.0 | 12.1 | - |
